Standard Equipment:

• Electrical

  • Alternator, 75-amp
  • Receptacle group, auxiliary start
  • Battery Disconnect Switch, Ground Level
  • Starter, electric, 24-volt
  • Diagnostic Connector
  • Engine Shutdown Switch
  • Lighting:
    – External, front, rear
    – Stop, single
  • Batteries, low maintenance
  • Alarm, reversing
  • Starting and Charging System

• Tires, Rims, And Wheels

  • Rims:
    – Tubeless, set of four
  • Tires must be selected from the Mandatory Attachments section, choose between:
    – Tire, 17.5 × R25 VSMS L5S Bridgestone
    – Tire, 17.5 × R25, VSDL Bridgestone

• Operator Environment

  • Caterpillar Electronic Monitoring System (CEMS), (dash instrument panels)
  • Horns, electric
  • Instrumentation/gauges:
    – Speedometer/tachometer
    – Fuel level
    – Hydraulic oil temperature
    – Engine coolant temperature
  • Light, warning, residual brake
  • Pilot Hydraulic Implement Controls, Single Joystick
  • Cab, ROPS and/or FOPS certified
  • Steering and Transmission Integrated Control (STIC^™) Steering
  • Seat, Suspension Tee with retractable seat belt

• Power Train

  • Engine:
    – Cat 3306B six cylinder, diesel
    – DITA (Direct Injection, Turbocharged, Aftercooled)
  • Precleaner, engine air intake
  • Fuel Priming Aid
  • Brakes, full hydraulic enclosed wet multiple-disc (SAFR)
  • Heat Shields
  • Torque Converter
  • Transmission Neutralizer
  • Transmission, automatic planetary power shift (4F/4R)

• Other Standard Equipment

  • Guards, engine and transmission
  • Bucket Dump (3.1 m3/4.1 yd3)
  • Catalytic Exhaust Purifier/Muffler
  • Cap, Radiator Manual Release
  • Decals, International Picto Graphics
  • Service oil sample
  • Fenders, Front, Rear
  • Firewall
  • Handholds
  • Hydraulic Oil Cooler, Swing Out
  • Valve, drain, transmission oil filter
  • Protection bars, rear frame
  • Radiator Grill, Swing Out

Optional Equipment:

• Tires, Rims, And Wheels

  • Rims:
    – Tube, set of four
    – Spare (Tube or Tubeless)
    – Rim Identification Numbering

• Optional Equipment

  • After-Treatment Options
    – DPF (Flow Through)
  • Brake Release Arrangements, Includes Steering Release
    – Recovery Hook
    – Recovery Bar
  • Bucket:
    – Cutting Edge, Bolt-On
    – Cutting Edge, Cat Weld On
    – Heel Shrouds, Ejector and Dump Buckets
    – Lip Fully Welded or Tack Welded
    – Mechanically Attached Wear Plate System (MAWPS)
    – Various Sizes, Dump (2.5 m3/3.2 yd3, 2.8 m3/3.7 yd3, 3.4 m3/4.4 yd3), Ejector (2.4 m3/3.1 yd3)
    – Standard Lip or Bolt-On Lip
    – Wear Bars, Ejector and Dump Buckets
    – Wear Liner
  • Covers:
    – Guard, for lift arm and front frame lights
    – Rear Grill (Additional Bolt-On Guard)
  • Draw Bar Attachment, Bolt-On
  • Fast Fill System:
    – Coolant
    – Engine Oil
    – Fuel
    – Hydraulic Oil
    – Transmission Oil
  • Fire Suppression System
    – Ansul, Powder Based
  • Fluids
    – Arctic Fuel
    – Arctic Coolant
  • Lifting Group, Mine Transfer
  • Lubrication System
    – Automatic
    – Centralized
  • Operators Station ROPS/FOPS Enclosed
    – Air Conditioning
    – Cab Pressurizer and Filter
    – Dome Light
    – Door Strut
    – Heater
    – Radio Ready Compartment for Radio and Speakers
    – Wiper Control, Intermittent
  • Park Brake Automatic Activation
  • Park Brake Switch Engagement
    – Push to Apply
    – Pull to Apply
  • Reflective Tape
  • Remote Control Interface (excludes Transmitter and Receiver), Includes Warning Lights (Green)
    – Cattron
    – RCT
  • Reversible Steering
  • Ride Control System
  • Rim
    – Tube Type
    – Tube or Tubeless (chain ready)
    – Spare (Tube or Tubeless)
    – Rim Identification Numbering
  • Secondary Steering System
  • Service Tools
    – Recovery Bar (for use with Brake Release, Recovery Bar System)
    – Reference Parts Manual for Additional Tooling Available
  • Switches
    – Idle Timer
    – Lift Arm Positioner
    – Transmission Neutralizer Override Switch
    – Transmission Pressure ABA Park Brake Engagement

• Operator Environment

  • Operator's Station ROPS/FOPS Enclosed:
    – Air Conditioning
    – Cab Pressurizer and Filter
    – Dome Light
    – Door Strut
    – Heater
    – Radio Ready Compartment for Radio and Speakers
    – Wiper Control, Intermittent
  • Instrumentation/gauges:
    – Brake pressures
  • Secondary Steering System

• Power Train

  • Engine:
    – After-Treatment Options – DPF (Flow Through)
  • Reversible Steering
  • Park Brake Automatic Activation
  • Park Brake Switch Engagement – Push to Apply/Pull to Apply
  • Radiator, High Efficiency
