Engine

Gross Power

74.8HP

Engine Model

Cat C3.3B

Operating Specifications

Standard Paving Range

1.75-3.42 m (5' 9" - 11' 2")

Maximum Paving Speed

210ft/min

Maximum Travel Speed

7mile/h

Maximum Paving Width

15.1ft

Weights

Operating Weight - With SE34 VT

19246lb

Tractor Weight

16094lb

Operating Weight - With SE34 V

18850lb

Service Refill Capacities

Fuel Tank Capacity

29gal (US)

Washdown Tank

6.2gal (US)

Dimensions

Operating Height - With Canopy

11.1ft

Transport Height - Canopy Retracted

8.6ft

Ground Contact Length

8.6ft

Operating Width

10.45ft

Transport Length

15.75ft

Transport Width

6.3ft

Truck Entry Height

21.5in

Truck Entry Width

10.3ft

Operating Length

16.5ft
